SR60+ 850mm cover width

Supplied plain galvanised as standard, with polyester white or additional coatings available on request

CALL NOW: 01787 275 055

Nationwide delivery

24 hour delivery

Quotes in 24 hours

A premium sinusoidal profile for industrial, commercial and distribution roof systems — 850mm cover width, 60mm depth, engineered for spans up to 5.2m with proven load performance across three steel gauges.

Available in galvanised and polyester white finishes, supplied to BS EN 10346:2015 and compliant with BS 5427:2019 (material) and BS 476 Pt7 (fire, Class 1). Its depth and wide coverage make it ideal for commercial, industrial and large-scale residential projects where strength, durability and fast installation matter.

The underside can stay exposed for an industrial look, or take a polyester white coating for a brighter soffit and less need for extra lining.

Watch this short video for a quick explanation!

HIGH-PERFORMANCE ROOF DECKING FOR MAJOR BUILDS

Efficient spanning: a 60mm depth in 0.7mm, 0.9mm or 1.2mm gauge spans longer with fewer supports, reducing secondary steelwork, saving install time and keeping roofing cost-efficient.
High load capacity: optimised section properties handle both gravity and uplift loads effectively, staying strong and stable under demanding conditions.
Corrosion resistance: available galvanised (Z275) or polyester white, suiting everything from standard commercial roofing to high-spec industrial applications.

Long lengths: manufactured up to 12m, reducing joints and speeding up installation.
Straightforward fixing: main fixing in every trough at supports with 150mm end laps for a quick, secure install.
Optimised handling: 850mm cover width gives excellent coverage while staying lightweight for on-site efficiency.
Reliable side laps: installed at 850mm centres for added stability and performance.

MAXIMUM SPAN, MAXIMUM COVERAGE

Features

Cover Width & Pitch

850mm cover width; 213mm pitch. Sinusoidal crown and valley geometry with 100mm and 62mm radii respectively.

Steel Grade & Thickness

S350 (BS EN 10143:2016, BS EN 10346:2015) in 0.7, 0.9, 1.2mm gauges. Maximum sheet length 12m.

Coatings

Galvanised Z275 (275g/m²) or Polyester White (150g/m² Z150 base + 25μm polyester topcoat).

Fire Performance

Class 1 (BS 476 Pt7); Class 0 surface rating available. Complies with BS 5427:2019.

Span Capability

2.0–5.2m depending on gauge, load case and deflection criteria. Partial safety factor 1.5 applied.

Fixing & Lap Details

Fixed every trough at sheet end; 150mm end lap, intermediate fixing every trough, 450mm side lap and 450mm side support spacing.

Benefits

Proven profile design: The 60mm depth sinusoidal profile provides excellent structural stiffness whilst maintaining practical cover widths and pitches. The 213mm pitch and curved crowns (100mm radius) and valleys (62mm radius) deliver both load capacity and weather performance.

Long span capability: SR60+ achieves spans from 2.0m to 5.2m depending on gauge and load case, reducing the need for intermediate supports and lowering support frame costs.

Material choice: Available in three gauges (0.7, 0.9, 1.2mm) from a single production line. Steel grades to BS EN 10143:2016 ensure consistent mechanical properties. Galvanised (Z275) and polyester white (Z150 + 25μm) coatings provide durability in exposed environments.

Fire compliance: Class 1 (BS 476 Pt7) and Class 0 surface rating where specified, supporting building regulations for medium-to-high-risk properties.

Applications

Industrial Facilities

Manufacturing plants, warehouses, factory units and production halls where robustness and long-span capability are essential.

Commercial Buildings

Retail, office canopies, terrace covers and extension roofing where aesthetic finish and weather tightness combine with structural performance.

Distribution & Logistics

Large-span sheds, storage facilities and consolidation centres requiring rapid installation and cost-effective roofing solutions.

Plant Room Enclosures

Covered plant areas including pump houses, boiler rooms and external equipment shelters with robust weather protection.

Roof Refurbishment

Re-roofing existing industrial and commercial structures where rapid installation minimises downtime and disruption.

TECHNICAL SPECIFICATION

Technical

Cover Width & Pitch

850mm cover width; 213mm pitch. Sinusoidal crown and valley geometry with 100mm and 62mm radius.

Steel Grade & Thickness

S350 (BS EN 10143:2016, BS EN 10346:2015) in 0.7, 0.9, 1.2mm gauges. Maximum sheet length 12m.

Coatings

Galvanised Z275 (275g/m²) or Polyester White (150g/m² Z150 base + 25μm polyester topcoat).

Fire Performance

Class 1 (BS 476 Pt7); Class 0 surface rating available. Complies with BS 5427:2019.

Span Capability

2.0–5.2m depending on gauge, load case and deflection criteria. Partial safety factor 1.5 applied.

Fixing & Lap Details

Fixed every trough at sheet end; 150mm end lap, intermediate fixing every trough, 450mm side lap and 450mm side support spacing
