SR100+ 720mm cover width

Supplied plain galvanised as standard, with polyester white or additional coatings available

CALL NOW: 01787 275 055

Nationwide delivery

24 hour delivery

Quotes in 24 hours

A deep sinusoidal profile for industrial, commercial and distribution roof systems — 720mm cover width, 100mm depth, engineered for spans up to 6.2m with proven load performance across three steel gauges (0.7mm, 0.9mm, 1.2mm). The long-span, high-load design reduces secondary steelwork for material and cost savings on large roof areas.

Available galvanised (Z275) or polyester-coated for long-term corrosion resistance, it's ideally suited to large-scale roofing where long spans, fewer purlins and high structural performance are essential — particularly industrial, commercial and distribution centre builds. The underside can be left exposed for an industrial finish or coated for a brighter look, including polyester white for better light reflection inside.

Watch this short video for a quick explanation!

DEEP-DECK ROOFING FOR LARGE-SCALE PROJECTS

High strength-to-weight ratio: excellent structural efficiency — despite being lightweight (9.47–16.29 kg/m² depending on gauge), it resists both gravity and uplift loads outstandingly, ideal for demanding roof designs.
Aesthetics & finishes: a range of colours and paint finishes can be applied to the underside for an attractive look while supporting fire safety compliance — contact us for details.
Alternative deep-deck roof profiles with similar span and load performance are also available.

Extended lengths: manufactured up to 12m to minimise joints and speed up installation.
Secure fixing: main fixings in every trough with 150mm end laps for robust connections.
Wide coverage: 720mm cover width and 240mm pitch balance installation efficiency with high structural performance.
Side lap security: installed at 450mm centres for stability under both gravity and uplift conditions.

HIGH-PERFORMANCE DECKING FOR DISTRIBUTION & INDUSTRIAL ROOFS

Features

Cover Width and Pitch

720mm cover width; 240mm pitch. Sinusoidal crown and valley geometry with 101mm and 70mm radius.

Steel Grade and Thickness

S350 (BS EN 10143:2016, BS EN 10346:2015) in 0.7, 0.9, 1.2mm gauges. Maximum sheet length 12m.

Coatings

Galvanised Z275 (275g/m²) or Polyester White (150g/m² Z150 base + 25μm polyester topcoat).

Fire Performance

Class 1 (BS 476 Pt7); Class 0 surface rating available. Complies with BS 5427:2019.

Span Capability

3.0m to 6.2m depending on gauge, load case and deflection criteria. Partial safety factor 1.5 applied.

Fixing and Lap Details

Fixed every trough at sheet ends and intermediate supports; 150mm end lap, 450mm side lap and 450mm side support spacing.

Benefits

Deep sinusoidal profile: The 100mm depth provides significantly greater structural stiffness than shallower sinusoidal sheets, allowing wider purlin spacings and longer spans. The 240mm pitch and curved crowns (101mm radius) and valleys (70mm radius) deliver both load capacity and effective water shedding.

Long span capability: SR100+ achieves spans from 3.0m to 6.2m depending on gauge and load case, significantly reducing the need for intermediate supports and lowering support frame costs on large roof areas.

Material choice: Available in three gauges (0.7, 0.9, 1.2mm) from a single production line. Steel grade S350 to BS EN 10143:2016 ensures consistent mechanical properties. Galvanised (Z275) and polyester white (Z150 + 25μm) coatings provide durability in exposed environments.

Fire compliance: Class 1 (BS 476 Pt7) and Class 0 surface rating where specified, supporting building regulations for medium to high risk properties.

Applications

Industrial Facilities

Manufacturing plants, warehouses, factory units and production halls where long span capability and structural stiffness are essential.

Commercial Buildings

Retail parks, office canopies and extension roofing where weather tightness, structural performance and a clean finish are all required.

Distribution and Logistics

Large span sheds, storage facilities and consolidation centres requiring rapid installation and cost effective roofing over wide purlin spacings.

Plant Room Enclosures

Covered plant areas including pump houses, boiler rooms and external equipment shelters with robust weather protection over wider spans.

Roof Refurbishment

Re-roofing existing industrial and commercial structures where the 100mm depth provides additional stiffness over deteriorated substrates.

TECHNICAL SPECIFICATION

Technical

Manufactured to BS EN 10346:2015 and compliant with BS 5427:2019 for roof sheeting, SR100+ achieves Class 1 fire rating (BS 476 Pt7) and can be specified for Class 0 surface assessment where building regulations demand enhanced fire safety.

The deep sinusoidal profile provides significantly greater structural stiffness than shallower profiles, making it the preferred choice for wide purlin spacings and long span applications where reducing support steelwork is a priority.

For more information, download our datasheet, or click here
